Waterproof Universal Off Road Fuse and Relay Power Distribution Center
Application
Any 12VDC Vehicle with added accessories that are too much draw for the vehicles factory power distribution system. Accessories such as an air ride compressor, lights, audio equipment, and fans. These are just a few examples; the opportunities are limitless.
THIS IS NOT FOR REWORKING AN LS HARNESS. PLEASE SEE PART NUMBERS 1010 or 1011.
Description
The Unit is roughly 8 x 3.5 inches and 5 inches tall.
Our Waterproof Universal Power Distribution Center is made of the highest quality materials. Cooper Bussman manufactures the fuse block, and we use genuine Aptiv (Formerly Delphi) terminals and seals to populate the Power Distribution Center. We also provide high-quality connectors and Aptiv (Formerly Delphi) heat shrink to make your connections to the fuse block! We guarantee you will love the heat shrink, as there is nothing better on the market! There is 3 foot of wire for power and ground and 8 foot of wire for the relay controls, relay outputs, and fused outputs providing plenty of mounting options! There are 5 fused relay circuits and 5 fuse only circuits!
Cooper Bussman rates the max working load of this fuse block at 80 amp.
1 – Main Power Supply – 8ga TXL Wire 3 Foot Long!
1 – Relay Coil Ground – 14ga TXL Wire 3 Foot Long!
5 – Relay Controls – 18ga TXL Wire 8 Foot Long!
5 – Relay Outputs – 12ga TXL Wire 8 Foot Long!
5 – Fuse Outputs – 16ga TXL Wire 8 Foot Long!
5 – 35 Amp Normally Open Relays
All needed fuses
Extra Fuses
OEM Aptiv (Formerly Delphi) Heat Shrink (This is the GOOD stuff!)
Uninsulated butt connectors for a good crimp and great connection when soldered after crimping!
Why BP Automotive?
All of the wire included in our products is TXL wire that meets or exceed OEM standards! This high temperature wire has maximum chemical resistance as well. Beware of many companies that use primary wire that has a much lower heat and abrasion tolerance and will not last against chemicals and heat. TXL wire is far superior in every way, don’t settle for less. We supply the same materials that are found in OEM vehicles, not parts stores, especially when it comes to the wire-that the coating will melt when the wire is soldered! We have also included stainless socket head bolts to hold the mounting brackets for a rust free, long lasting good look!
Additional Info
This Power Distribution Center will require some knowledge to install and use it. It is wired for an easy install and includes a diagram so that you can wire it to your application. Due to the universal nature of this item it is impossible to provide exact diagrams for your applications! However, the universal nature of this item really makes your install options limitless!
