LS Swap GM A/C Pressure Sensor T in Fitting

LS Swap GM A/C Pressure Sensor T in Fitting – Brass

Maintain factory-level drivability in your LS-swapped vehicle by integrating the GM A/C pressure sensor directly into your high-side line. This high-quality brass thread-in fitting allows your ECM or PCM to monitor system pressure, enabling the computer to bump the idle and automatically trigger the cooling fans when the A/C is in use. (Idle bump feature is available on most OS options; however, some may not bump the idle on pressure alone.

Technical Specifications

• Material: Premium Brass for superior corrosion resistance and a leak-free seal.

• Installation Type: Thread-in (Designed for easy installation into existing high-side ports).

• System Location: High-Pressure (Discharge) side only.

• Sensor Side Thread Pitch: M10x1.25 (Specifically threaded for the GM A/C Pressure Sensor).

• Line Side Thread Pitch: #6 Threaded Hose.

• Function: Provides the ECM with the necessary data for idle compensation and fan pulse-width modulation (PWM) or relay control.

Installation Note

This fitting is intended for use on the High Side of your A/C system. For proper operation, the GM sensor must be able to read the discharge pressure so the ECM knows when to increase fan speeds to keep head pressures in check.

Related LS A/C Solutions

If this thread-in fitting is not the right fit for your plumbing, we offer several other professional integration options:

• AC Pressure Sensor: ACS-001 – Ideal for custom aluminum or steel hard lines.

• Weld-In Kit (Fitting & Sensor): ACK-001 – Ideal for custom aluminum or steel hard lines.

• Crimp-In Kit (Fitting & Sensor): ACK-002 – Designed for #8 Standard Barrier A/C hoses.

• Binary Safety Switch: ACS-002 – Standalone high/low-pressure safety

• Crimp-In Binary Switch Fitting: ACF-006 – Crimp-in fitting with a 7/16″ port for binary switches.
